Does an Automatic Die-Cutting Machine Need 600T Pressure?

You're specifying a die-cutting press for folding cartons, corrugated boxes, or specialty packaging, and the spec sheet lists a maximum working pressure of 600 tons. Is that much force really necessary, or is it overkill? An Automatic Die-Cutting Machine with high pressure capability handles the full range of materials—from lightweight cardstock to thick corrugated board—without slowing down or producing incomplete cuts. This article explains what the pressure rating means in practice, how the machine maintains precision at high force, and what to verify before selecting a platen die-cutter for your packaging production.

What Does the Pressure Rating Mean for Die-Cutting?

The maximum working pressure defines the force the machine can apply between the die and the platen. Higher pressure allows the machine to cut through thicker, denser materials without compromising cut quality. The JX-1060M series is rated for 300T to 600T maximum working pressure, depending on the model. This range covers the majority of packaging applications, from folding cartons to corrugated boxes. The pressure is automatically regulated by the machine's control system, and an analog plate frame with an intermediate positioning system and fine-tuning device allows precise adjustment for each job.

Matching Pressure to Material Thickness**

Different materials require different cutting forces. Lightweight cardboard may cut cleanly at 300T, while corrugated board up to 4mm thick may require the full 600T. The machine's automatic pressure adjustment system delivers swift and precise stamping pressure control, allowing operators to dial in the correct force for each substrate without trial-and-error.

How Precision Is Maintained at High Pressure**

High pressure can cause deflection if the machine frame isn't rigid enough. The JX-1060M uses a body made from ductile iron QT600-7, a material with high tensile strength and permanent deformation resistance. The main frame and pressure-bearing components are cast with special processes to maintain geometry under repeated high-pressure cycles.

How Does the Machine Achieve 7500 Sheets Per Hour?

Speed and precision don't always go together—but the JX-1060M maintains ≤±0.1mm die-cutting precision at a maximum working speed of 7500 sheets per hour. This combination of speed and accuracy comes from several design choices: a Taiwan-imported indexing mechanism for precise motion, an Inovance PLC for smooth machine operation, and a German Becker vacuum pump for reliable feeder paper transport.

Taiwan-Imported Indexing Mechanism**

The high-precision 240-degree indexing mechanism imported from Taiwan ensures accurate machine action at high speed. This mechanism coordinates the motion of the feeder, die-cutting unit, and delivery, maintaining registration even as the machine accelerates.

Inovance PLC and Becker Vacuum Pump**

The main PLC uses Inovance Technology to ensure smooth machine operation. The vacuum pump employs German Becker to ensure smooth feeder paper transport. Together, these components keep the paper moving through the machine without jams or misfeeds, even at 7500 sheets per hour.

What Materials Can the Machine Process?

The JX-1060M handles a wide range of packaging materials. Paper specifications range from 80-2000g/m² cardboard, with the ability to process corrugated paper up to 4mm in thickness. The maximum feeding paper size is 1060×750mm, and the maximum die-cutting area is 1020×730mm.

Cardboard and Corrugated Board Compatibility**

The machine's pressure range covers both cardboard and corrugated board. For folding cartons and lightweight packaging, the lower end of the pressure range is sufficient. For corrugated boxes and heavy-duty packaging, the full 600T capability ensures clean cuts through the material.

Gripper Margin and Feed Pile Height**

The gripper margin is adjustable from 8-17mm, accommodating different sheet sizes and registration requirements. The maximum feed pile height is 1600mm including wooden pallets, allowing extended production runs between reloads.

What Control and Automation Features Are Included?

The JX-1060M is designed for automated operation with minimal manual intervention. The machine uses a Chinese/English touch screen operating interface, and the delivery section features its own 10.4-inch touchscreen for control. The delivery unit includes an automatic auxiliary delivery function for non-stop operation, and the paper feeding table can be controlled independently.

Non-Stop Delivery and Automatic Stacking**

The delivery section includes a non-stop unit for continuous operation. An automatic paper aligner and dual-path air blowing device ensure neat stacking for both thick and thin paper. Photoelectric detection at the delivery ensures neat paper stacking, and the automatic lifting/lowering control system manages the delivery pile.

Automatic Lubrication and Cooling**

The machine features an automatic lubrication system with an oil pump equipped with an auto-cooling fan device. The high-power oil supply lubrication system ensures lubrication during long-term high-speed operation of the main unit, and an oil pressure display and abnormal oil pressure alarm device keep the operator informed of the system status.

Which Optional Components Expand Capability?

The JX-1060M supports a range of optional components that expand its capability beyond standard die-cutting. The machine can be configured with a pre-code paper mechanism, and the delivery section can be equipped with additional automation features.

• Pre-code paper mechanism — optional one set for coded paper handling

• Non-stop delivery unit — for continuous operation without stopping

• Automatic auxiliary delivery function — non-stop operation at the delivery section

• Dual-path air blowing device — ensures neat stacking for thick and thin paper

Pre-Code Paper Mechanism for Specialized Jobs**

The optional pre-code paper mechanism allows the machine to handle coded paper sheets, expanding the range of applications beyond standard die-cutting and creasing.

Non-Stop Delivery for Continuous Production**

The non-stop delivery unit enables the machine to continue operating while finished stacks are removed. This reduces downtime and keeps production running at maximum speed.

Common Questions About Platen Die-Cutting Machines

What is the maximum die-cutting precision?**

The JX-1060M achieves ≤±0.1mm die-cutting precision. This level of accuracy is maintained across the full speed range of 7500 sheets per hour.

Can the machine handle corrugated board?**

Yes. The machine processes corrugated paper up to 4mm in thickness, in addition to cardboard from 80-2000g/m².

What safety features are included?**

The main unit has an overload protection device that ensures immediate shutdown upon external impact to reduce damage to the machine body and cutting precision. The machine also includes main chain protection, anti-paper-retraction device, and gripper bar groove protection.

What maintenance does the machine require?**

Routine maintenance includes regular cleaning of the cutting head, lubricating moving parts, and checking the oil pressure and lubrication system. The automatic lubrication system with cooling fan reduces manual maintenance requirements.

Request a Die-Cutting Configuration for Your Production

An Automatic Die-Cutting Machine with 300T-600T pressure, ≤±0.1mm precision, and 7500 sheets/hour speed is the practical choice for cardboard and corrugated packaging production. The JX-1060M/JX-1060MZ from Jiexiang delivers ductile iron QT600-7 construction, Taiwan-imported indexing mechanism, Inovance PLC control, German Becker vacuum pump, and optional pre-code paper mechanism. Contact Jiexiang for a die-cutting configuration assessment → their team can help you select the right model, pressure rating, and optional components for your specific packaging materials and production targets.
